Kenworth T480 Chassis
PACCAR PX-9 450HP Engine
Allison EVS 3000 Transmission
Seating: 2-man cab
Front Axle: 14,600 lbs.
Rear Axle: 40,000 lbs.
Wheelbase: 231”
Amdor Roll-up Doors
Driver Side Hard Suction Storage
(2) Hard Suction Hoses (6” x 10’)
Officer Side Portable Tank Storage
SCBA Bottle Storage for (4)
Durable Compartment Finish
3000 Gallon Folding Tank
Vinyl Crosslay Cover and Hosebed Cover
Hale RSD 1500 GPM Pump
3,000 Gallons Water
(2) 2.5” Drive Side Discharge
(1) 3” Officer Side Discharge
(1) 2.5” Officer Side Discharge
(2) 1.75” Preconnects
FRC PumpBoss Pressure Governor
Innovative Controls
(1) 2.5” and (1) 4” Direct Tank Fill with Fireman’s Friend Valves
Rear Electric Dump with Swivel and Extension
Whelen LED Warning & Scene Light Package
Upfit Capabilities:
Apparatus body and storage upfits
Front bumper configurations
Chassis customizations
Add/omit discharges, reclassify pump GPM if needed
Foam system upgrades or additions
Equipment sales
Lighting and siren updates
Specialty rescue equipment integration (e.g., Hazmat, Technical Rescue)
